PVC Saddle Clamp
The PVC Saddle Clamp Is A Lightweight, Inexpensive Saddle Clamp Made Of PVC And Can Be Used On PVC Pipes To Divert Water From The Main Pipe To The Branch Pipe.
Specification
Dimension Test standard ISO4422-3
Oven Test standard ISO12092:2000
Falling test standard GB/T 8801-2007
Appearance inspection requirement
The inner and outer surfaces of the product should be smooth, and defects such as delamination, obvious bubbles, marks, cold spots and uneven color are not allowed
Connection for PVC pipe
Suitable for potable water ,neutral liquids and sewage
Product video
Drawing
Material
| Sr.No. | Name | Material |
|---|---|---|
| 1&2 | Body | PVC |
| 3 | Gasket | EPDM |
| 4 | Bolts,nuts and washers | SS304(A2) |
Bolts can be Dacromet coated carbon steel ,teflon coated stainless steel material or upon client request
Dimension(unit mm)
| PVC ODXRp | h | Z | L |
|---|---|---|---|
| 50X25 | 26 | 59 | 23 |
| 63X25 | 26 | 65 | 28 |
| 63X1" | 21 | 60 | 28 |
| 75X 1 1/2" | 24 | 68 | 31 |
| 90X25 | 26 | 80 | 36 |
| 90X1" | 24 | 79.5 | 36 |
| 90X 1 1/2" | 24 | 75 | 36 |
| 110X1/2" | 24 | 88.5 | 38 |
| 110X1" | 24 | 88.5 | 38 |
| 110X 1 1/2" | 35 | 97 | 38 |
| 110X2" | 35 | 97 | 38 |
| 110X 2 1/2" | 35 | 97 | 38 |
| 125X 1 1/2" | 37 | 105 | 37 |
| 125X2" | 37 | 105 | 37 |
| 125X 2 1/2" | 37 | 105 | 37 |
| 160X1/2" | 36 | 125 | 55 |
| 160X3/4" | 36 | 125 | 55 |
| 160X1" | 24 | 114.5 | 55 |
| 160 X1 1/2" | 36 | 125 | 55 |
| 160x2" | 36 | 125 | 55 |
| 160 2 1/2" | 36 | 125 | 55 |
| 200 1 1/2" | 35 | 142 | 74 |
| 200X2" | 37 | 142 | 74 |
| 200 X2 1/2" | 37 | 142 | 74 |
| 225X1 1/2" | 37 | 153.5 | 76 |
| 225x2" | 37 | 153.5 | 76 |
| 225X2 1/2" | 37 | 153.5 | 76 |
| 250X2" | 28 | 170 | 76 |
| 250X2 1/2" | 38 | 170 | 76 |
| 250X3" | 34 | 170 | 76 |
| 250X110 | 61.5 | 195 | 76 |
| 315X2" | 27 | 170 | 70 |
| 315X110 | 63 | 231.5 | 70 |
| 315X160 | 86 | 250 | 70 |
| 400X110 | 61 | 285 | 87 |
| 400X200 | 106 | 330 | 87 |
| 400X250 | 162 | 385 | 87 |
Big size also available upon request
PVC Saddle Clamp Sizes
PVC saddle clamps come in various sizes to accommodate different main pipe diameters and branch pipe requirements. The sizes typically vary based on the outer diameter (OD) of the main pipe they are intended to clamp onto, as well as the size of the outlet connection for the branch pipe. Here are some common PVC saddle clamp sizes and their corresponding main pipe and outlet sizes:
Common Main Pipe Sizes
PVC saddle clamps are designed to fit a range of main pipe sizes. Here are some typical sizes for the main pipe (OD):
- OD50mm
- OD63mm
- OD75mm
- OD90mm
- OD110mm
- OD125mm
- OD160mm
- OD200mm
- OD225mm
- OD250mm
- OD315mm
- OD400mm
Common Outlet (Branch) Sizes
The outlet size on the PVC saddle clamp can vary to match the size of the branch pipe being connected. Here are some typical outlet sizes:
- 1/2 inch
- 3/4 inch
- 1 inch
- 1.5 inches
- 2 inches
- 3 inches
Size Combinations
A PVC saddle clamp’s size is usually indicated by a combination of the main pipe size and the outlet size. But the maximum thread outlet size is 3″, big size haven’t enough strength so bigger than 3″ outlet thread size is not available. and normally the outlet size is smaller than main pipe size.For example you can’t get a 3″ thread outlet size from a pipe which outside diameter is smaller than OD90. The size combinations examples as below for your reference:
- OD50mm main pipe with 1/2 inch outlet
- OD75mm main pipe with 3/4 inch outlet
- OD110mm main pipe with 1 inch outlet
- OD160mm main pipe with 2 inch outlet
Considerations for Selection
When selecting a PVC saddle clamp, consider the following:
- Main Pipe Diameter: Ensure the saddle clamp fits the OD of the main pipe.
- Branch Pipe Diameter: Choose an outlet size that matches the branch pipe size.
- Pressure Rating: Verify that the saddle clamp can withstand the operating pressure of the system.
- Installation Environment: Ensure the material is suitable for the environmental conditions, including UV exposure if used outdoors.
Example Sizes and Specifications
- For a 2-inch main pipe:
- Outlet sizes could include 1/2 inch, 3/4 inch, or 1 inch.
- For a 4-inch main pipe:
- Outlet sizes could include 3/4 inch, 1 inch, or 1.5 inches.
- For a 6-inch main pipe:
- Outlet sizes could include 1 inch, 1.5 inches, or 2 inches.
Conclusion
PVC saddle clamps come in a variety of sizes to fit different main pipe diameters and branch pipe requirements. It’s important to select the appropriate size based on the specific needs of your piping system to ensure a secure and effective connection. Always refer to the manufacturer‘s specifications for precise dimensions and compatibility.
PVC Saddle Clamp Price
PVC saddle clamp prices can vary based on size, material, and specific application needs. Here are some example prices for different sizes and types of PVC saddle clamps:
- 2″ x 3/4″ PVC Clamp Saddle: $8
- 4″ x 1″ PVC Clamp Saddle: $10
- 6″ x 2″ PVC Clamp Saddle: $12
- 8″ x 4″ PVC Clamp Saddle: $15
These prices reflect standard options and can vary depending on the supplier and any additional features or materials used. For more detailed pricing, please contact us.
